| Power Supply | 3P+N+PE |
| Input Voltage | 380V/AC ±15% |
| Input Frequency | 50/60 Hz |
| Input PF | ≥0.98 (20%–100% load) |
| Total Harmonics of Input Current | ≤5% (50%–100% load) |
| Rated Power | 20kW |
| Voltage Range | 200–1000V/DC |
| Constant Power Output Voltage Range | 300–1000V/DC |
| Maximum Current | 63A |
| Peak efficiency | ≥95% (50%–100% load) |
| Steady Current Accuracy | ≤±1% |
| Steady Voltage Accuracy | ≤±0.5% |
| LED Indicator | LED (blue, green, red) |
| LCD Display | 10.1″ Touch LCD Screen |
| Start Mode | RFID Reader, Plug & Play, APP |
| Cable Length | Option |
| PCS of connector | Single |
| LAN | Yes |
| 4G | Yes (option) |
| OCPP | OCPP1.6J |
| Electrical Protection | Short Circuit Protection; Over Load Protection; Over Temperature Protection; Leakage Protection; Over and Under Input Voltage Protection; Over and Under Output Voltage Protection; Over-current Protection |
| Ingress Protection | IP54 |
| Noise | II |
| Cooling Method | Fan Cooling |
| Impact Protection | IK10 |
| RCD | 30mA DC |
| Energy Meter | Standard configuration |
| Work Temperature | −30°C to +55°C |
| Storage Temperature | −40°C to +70°C |
| Relative Humidity | ≤95% Dew Free |
| Work Altitude | ≤2000 m |
| Environmental Conditions | Indoor or Outdoor |
| Installation | Wall-mount or Pole-mount |
| Product Dimension | 780 × 600 × 215 mm (H × W × D) |
| Net Weight | 72 kg |
| External Package | Wooden case |
